Extended Product Type:I/O base

Product ID:TSXDMZ28AR

Discrete Input Number:16

Screw Terminal Block:Yes

Discrete Input Voltage:100…120 V AC

Discrete Input Current:11 mA, 13 mA

Current Consumption:125 mA

Power Dissipation:5.6 W

Power Consumption:40 W

Rated Load:24 V DC-12 resistive, 24 V DC-13 inductive

Weight:1.1 lb (0.5 kg)

    The Schneider TSXDMZ28AR Discrete Relay I/O Base is a high-quality component engineered to meet the demanding requirements of industrial automation systems. It is designed to manage digital signals with precision and reliability, ensuring smooth operation in various industrial settings.

    This module comes equipped with 16 screw terminal blocks, allowing for secure and efficient connection of discrete inputs. Its input voltage ranges from 100V to 120V AC, making it compatible with a wide array of applications.

    The discrete input current rating of 11 mA and 13 mA ensures efficient signal processing without excessive power consumption. With a current consumption of 125 mA and power dissipation of 5.6 W, this module operates efficiently even under heavy load conditions.

    Built for durability and long-lasting performance, the TSXDMZ28AR I/O Base is crafted from premium materials designed to withstand harsh industrial environments. Its robust design ensures minimal downtime and maximum operational efficiency.

    Installation is straightforward, thanks to clear wiring diagrams and intuitive design. This module integrates seamlessly with existing Schneider PLC systems, making it an ideal choice for system upgrades or new installations.
