Manufacturer:GE Industrial Systems

Series:Ex2100 Excitation Control

Part Number:IS200DSPXH1DBC

Functional Description:Digital Signal Processor Control Board

Functional Acronym:DSPX

PCB Coating:Conformal Coating

Functional Revision:1D

Artwork Revision:C

Clock Speed:60 MHz

Interfaces:Two (Master or Slave) 5 Mb/s ISBus interfaces

Onboard Memory:FLASH, RAM, NVRAM

    The IS200DSPXH1DBC is a critical component for managing industrial automation processes, designed with robust technology to ensure precision and reliability.

    Equipped with a 60 MHz digital signal processor and an application-specific integrated circuit (ASIC), this board provides unparalleled accuracy in motor and bridge regulation.

    With a 5V power supply input, the board is easily integrated into existing systems, reducing installation time and complexity.

    The board includes two LED indicators for fault and status monitoring, providing real-time feedback on system performance.

    This digital signal processor control board comes with onboard firmware that includes application code, boot loader, and configuration parameters, ensuring seamless operation and easy maintenance.
